Cushman Hauler PRO-X Electric

Out of stock

Call for Price

SKU 87a425fff1de Category
Request a Quote
Quote by Phone
Request Brochure

Description

Description

The Hauler® PRO-X boasts electric power designed to stand up to any challenge, with rugged tires and extra ground clearance that’s ready to take you places other electric vehicles would never venture. And while this uncompromising performance makes a loud-and-clear statement, the 72V electric drivetrain delivers silent power right when you need it.

Features
  • 72V AC Electric Drivetrain: Unrivaled AC power, efficiency and a 50-mile range.
  • Highly-Functional Dash: Industry-leading storage and control at your fingertips.
  • Lifted Suspension: Added ground clearance for challenging terrain.
  • 12-cu-ft Cargo Bed: Generous, customizable space for tools and supplies.
  • Optional Aluminum Bed/Power Dump: Lighten up your workday.
  • On-board Charger: The flexibility to charge from anywhere.
Key Features
  • 72V AC Electric Drivetrain
  • 900-lb Vehicle Load Capacity
  • 500-lb Bed Load Capacity
  • 1,200-lb Towing Capacity
  • 12-cu-ft Cargo Bed
  • 2-Passenger Seating
Body & Chassis
  • Frame: Welded Steel with DuraShieldâ„¢ Powder Coat
  • Body & Finish: Injection Molded TPO
  • Standard Color: Forest Green / Patriot Blue
Dimensions
  • Overall Length: 119 in (302.3 cm)
  • Overall Width: 49.4 in (125.5 cm)
  • Overall Height: 52.5 in (133 cm) (w/o Roof) 77.0 in (195.6 cm) (w/ Struts & Roof)
  • Wheel Base: 77.5 in (196.9 cm)
  • Wheel Track: 38.0 in (96.5 cm) Front 38.5 in (97.8 cm) Rear
  • Ground Clearance: 7.2 in (18.29 cm)
  • Cargo Deck Capacity: 12-cu-ft (0.34 m3)
  • Cargo Deck Material: Roto-Molded Polyethylene
Power
  • Power Source: 72V DC
  • Horsepower (KW): 22.4HP (16.7 kW) – Measured at Peak Torque
  • Electrical System: 72V
  • Battery (Qty/Type): Nine, 8V Deep Cycle
  • Battery Charger: 900 Watt 72V DC
  • Key or Pedal Start: Pedal
  • Speed Controller: 350 Amp AC
  • Drive Train: Motor Shaft Direct Drive
  • Transaxle: Differential w/ Helical Gears
  • Gear Selection: Seatwrap-Mounted Forward-Neutral-Reverse
  • Rear Axle Ratio: 17:01
Performance
  • Seating Capacity: 2-Person
  • Weight w/o Batteries: 948 lb (430 kg)
  • Curb Weight: 1513 lb (686 kg)
  • Vehicle Load Capacity: 900 lb (408 kg)
  • Bed Load Capacity: 500 lb (227 kg)
  • Towing Capacity: 1200 lb (544 kg) max
  • Outside Clearance Circle: 23.5 ft (7.2 m)
  • Speed: 16.5 mph ± 0.5 mph (26.6 kph ± 0.8 kph)
Steering & Suspension
  • Steering: Self-Compensating Rack & Pinion
  • Suspension: Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear)
  • Service Brake: Rear Wheel Mechanical, Self-Adjusting Drum
  • Parking Brake: Self-Compensating, Single-Point Engagement
  • Tires: 20 x 8.0 – 10
