E-Z-GO RXV ELiTE

Out of stock

Call for Price

SKU 320168e1fd7f Category
Request a Quote
Quote by Phone
Request Brochure

Description

Description

As the long-standing leader in golf car innovation, AC drivetrain efficiency and IntelliBrake™ technology, the E-Z-GO® RXV® continues to raise the bar on superior golf car performance. No other vehicle delivers reliable, efficient performance and a host of upgraded features like the RXV.

Model Features
  • Zero maintenance lithium batteries
  • Faster charge times (compared to traditional lead acid batteries)
  • Opportunity charging
Features
  • Impact Resistant Bumper
  • Industry’s Largest Bagwell
  • Contoured Seats
  • Integrated Cup, Ball & Tee Holders
  • Optional USB Port
  • Optional Fold-Down Windshield
Body & Chassis
  • Frame: Welded steel with epoxy coating
  • Body & Finish: TPO
  • Available Colors: Forest Green
Dimensions
  • Overall Length: 94.5 in (240 cm)
  • Overall Width: 47.0 in (119 cm)
  • Overall Height: 45.7 in (116 cm) (top of steering wheel) 68.5 in (174 cm) (top of sun canopy)
  • Wheel Base: 65.7 in (167 cm)
  • Wheel Track: (Front) 35.5 in (90 cm) (Rear) 38 in (97 cm)
  • Ground Clearance: 4.5 in (11 cm) at differential
Power
  • Power Source: 48-volt DC
  • Horsepower (KW): 4.4 hp (3.3 kW) continuous
  • Electrical System: 48-volt
  • Battery (Qty/Type): Two, 48V Lithium ELiTE
  • Battery Charger: Lithium World Charger 48VDC (11 ft., 18 ft.) Cord
  • Speed Controller: 235 Amp AC Controller
  • Drive Train: Motor shaft direct drive
  • Transaxle: Limited slip differential
  • Gear Selection: Dash-mounted forward-neutral-reverse (Integrated into key switch)
  • Rear Axle Ratio: 16.99:1
Performance
  • Seating Capacity: 2-Person
  • Weight w/o Batteries: 658 lb (298 kg)
  • Curb Weight: 707 lb (320 kg)
  • Vehicle Load Capacity: 800 lb (360 kg)
  • Towing Capacity: 3 E-Z-GO golf cars with approved tow bars
  • Outside Clearance Circle: 19.2 ft (5.8 m)
  • Speed: 8-15 mph (13-24 kph) programmable (level ground)
Steering & Suspension
  • Steering: Double-ended rack and pinion
  • Suspension: (Front) Independent A-arm coil over shock (Rear) Mono-Leaf springs with hydraulic shock absorbers
  • Service Brake: Induction motor
  • Parking Brake: Automatic electro-magnetic
  • Tires: Turf 18 x 8.50-8 (4-ply rated)
