Jacobsen SLF530 4WD

Out of stock

Call for Price

SKU 0456cb87f224 Category
Request a Quote
Quote by Phone
Request Brochure

Description

Description

Introducing the SLF530, a versatile mower delivering an unrivalled quality of cut with a superb power to weight ratio. Designed with productivity and maneuverability in mind, the SLF530 is packed full of standard functionality, including a high-res full colour screen which puts advanced on-board diagnostics at your fingertips. With Jacobsen’s renowned quality-of-cut the SLF530 is the perfect choice for golf, sports and fine turf where appearance is paramount.

Engine
  • Type: Kubota® D1105 liquid cooled, diesel
  • Rated Horsepower: 24.8 hp @ 3000 rpm
  • Emission Level: EU Stage IIIB – (EPA Tier 4 Final)
  • Cooling System: Side-by-side radiator/hydraulic oil cooler, pressurised
  • Fuel Capacity: 6.4 gal.
  • Electrical System: 12 V starter, input/output controller. 60 amp alternator. Overload protection with automative type fuses.
Speed (Maximum)
  • Mowing: 6.3 mph
  • Transport: 8.7 mph
  • Reverse: 3.7 mph
Traction and Drive
  • Traction System: 4WD Pure Parallel 4-wheel system with selectable 2 or 4-wheel drive and automatic 2-wheel drive in reverse
  • Cutting Unit Drive: Fixed displacement hydraulic motors
  • Hydraulic System: 10 micron remote charge filtration, suction screen at tank, oil cooler, side-by-side radiator
  • Hydraulic Cooling: Side-by-side pressurised hydraulic oil cooler
Tires, Brakes, and Steering
  • Front Tires: 22 in. tubeless
  • Rear Tires: 20 in. tubeless
  • Parking Brake: Wet parking brakes integrated into hweel motors
  • Steering: Hydrostatic powered equal displacement cylinder to rear wheels
  • Service Brake: Hydrostatic braking
Reels and Blades
  • Number and Size: Five 5 in. diameter x 18 in.
  • Number of Blades: 8 and 11 blades
  • Cutting Frequency: 8 blade: 0.067 in./mph; 11 blade: 0.049 in./mph
  • Overall Cutting Width: 82 in.
  • Height-of-Cut: 0.30 – 0.70 in. Available high-cut kit raises cutting height to 0.937 in. using low profile, heavy bedknife
Weight and Dimensions
  • Weight: 4WD – 2053 lbs
  • Length: 102 in.
  • Height: 82 in. including ROPS
  • Transport Width: 98 in.
  • Width-of-Cut: 82 in.
Performance
  • Classic XP Reels: Durable 45.7 cm (18â€�) reels with TrueSet bedknife adjustment delivers superior cut quality and follows ground contours.
  • Slope capability: Superior slope capability and traction keeps the machine stable and operators safe.
Simplicity
  • FlashAttach™ cutting unit mounting system: Less maintenance time. No tools required for removal or installation.
  • On-board diagnostics: The industry’s only full-color LCD screen displays simple and accessible information saves operators and service teams time and money.
Options
  • 3WD and 4WD: Choose your preferred configuration to suit your application.
  • Reels: Several legendary Jacobsen reel options are available to suit any application.
  • Tires: Slick or treaded tires available. *See specification sheet for all available options.
