The RXV® is known on golf courses everywhere for its superiority under the seat. Whether it’s the industry-leading ELiTE® lithium battery powered by Samsung SDI technology or first-of-its-kind EX1® gas engine with closed-loop EFI, the RXV is a low-maintenance, high-performance golf cart you can always rely on. And now, the RXV creates a noticeable difference for golfers too, with a purpose-built dash and automotive pedals that completely streamline the way they play. Turn your course into a player’s paradise with a custom fleet of RXVs.
OVERALL LENGTH 92.5 in (235 cm)
OVERALL WIDTH 45 in (114 cm)
OVERALL HEIGHT (W/O ROOF) 47.5 (121 cm)
OVERALL HEIGHT (W/ ROOF) 67 in (170 cm)
WHEEL BASE 65.7 (167 cm)
FRONT WHEEL TRACK 35.5 (90 cm)
REAR WHEEL TRACK 38 (97 cm)
GROUND CLEARANCE @ DIFFERENTIAL 4.5 in (11 cm)
POWER SOURCE 56.7-VDC
HORSEPOWER (KW) 4.4 hp (3.3 Kw) Continuous
ELECTRICAL SYSTEM 48 Volt AC
BATTERIES (QTY/TYPE) ELiTE 2.2, 56.7V Lithium
KEY OR PEDAL START Pedal
BATTERY CHARGER Lithium World Charger 56VDC 10 ft. DC Cord
SPEED CONTROLLER 235-amp Solid-State AC Controller
DRIVETRAIN Motor Shaft Direct Drive
TRANSAXLE Limited Slip Differential
GEAR SELECTION Dash Mounted Forward-Neutral-Reverse
REAR AXLE RATIO 16.99:1
SEATING CAPACITY 2 Passenger
DRY WEIGHT (W/ CANOPY) 633 lb (287 kg)
CURB WEIGHT (W/ CANOPY) 680 lb (308 kg)
VEHICLE LOAD CAPACITY 500 lb (227 kg) (2 Passenger) or 800 lb (360kg) (4 Passenger)
OUTSIDE CLEARANCE CIRCLE 19.2 ft (5.9 m)
SPEED (LEVEL GROUND) 12 mph ± 0.5 mph (19.3 kph ± 0.8 kph)
TOWING CAPACITY Three E-Z-GO Golf Cars with Approved Permanent Tow Bar
STEERING Double Ended Rack & Pinion
SUSPENSION Independent A-Arm Coil Over Shock (Front) –
Mono-Leaf Springs with Hydraulic Shocks (Rear)
SERVICE BRAKE Induction Motor
PARKING BRAKE Automatic Electro-Magnetic
TIRES 18 x 8.50-8 (4-ply rated)
FRAME Welded Steel with Powder-Coat Protection
BODY & FINISH Injection Molded TPO
AVAILABLE BODY COLORS Almond, Black, Bright White, Forest Green, Inferno Red, Ivory, Matte Green
Metallic Charcoal, Ocean Grey, Patriot Blue, Platinum, Slate
STANDARD SEAT COLORS Black, Grey, Stone Beige
PREMIUM SEAT COLORS Black, Mushroom, Grey, White (Custom Colors Available)
SIGNATURE SEAT Amarillo Brown, Tundra Grey (Cool Touch)
PINSTRIPE COLORS Silver, Black, Gold
