E-Z-GO Liberty

SKU ae86ded9c422-1 Category
Request a Quote
Quote by Phone
Request Brochure

Description

Description

The E‑Z‑GO® Liberty is a first-of-its-kind vehicle pushing everything in a new direction with its four-forward facing seats. As an ELiTE lithium vehicle the E‑Z‑GO Liberty is powered by a proven, maintenance-free Samsung SDI lithium battery system that will propel your next adventure. Make the best of every moment while experiencing unmatched maneuverability, increased comfort and more performance. Explore your next adventure with the E‑Z‑GO Liberty.

The E‑Z‑GO Liberty is offered exclusively as an ELiTE Lithium vehicle. Get consistent power regardless of your level of charge, and charge any time you like, faster and more efficiently than with standard, lead-acid batteries.*

Make the most of your Liberty with our mount accessories including a hitch mounted storage receiver and a 4 bag holder.

The Premium Interior offers lighted cupholders, premium steering wheel, land individual key switch, glove box door, mats and shelf.

Enjoy a spacious and secure second row that will give your passengers a whole new perspective.

With its optimized wheelbase, Liberty gives you a tighter turning radius and enhanced maneuverability.

Key Features

• The Industry’s First Four Forward-Facing Seats

• Premium Steering Wheel

• Functional Dash with Versatile Cup and Technology Holders, Plus Three Storage Areas

• LED Headlights

• Brake Lights

• USB Ports

• Base Packages Customized for Every Rider

Commuter Package
• Paramount M/T Tires on SPDR Wheels
• Convex Mirror
• Fender Flares
• Brushguard
Links Package
• Loadstar Tires on Daytona Alloy Wheels
• Top Speed 14.5 Mph (23 Kph)
• 4-Bag Holder Attachment (Accessory)
• Sand Bottle Holder (Accessory)
Dimensions
  • Overall Length: 106.5 in (271 cm)
  • Overall Width: 48 in (122 cm)
  • Overall Height: 54.5 in (138 cm), 78 in (198 cm) w/ roof
  • Wheel Base: 76 in (193 cm)
  • Wheel Track: 37.5 in (95 cm) front/ 39 in (99 cm) rear
  • Ground Clearance: 7 in (18 cm)
Power
  • Power Source: 56.7V DC, AC induction motor
  • Horsepower 11.7 hp (8.7 kW)
  • Electrical System: 56.7V
  • Battery (Qty/Type): Single, 56.7 Vol Li-Ion Composite Module (Standard Configuration)
  • Battery Charger: 56.7 V 350 W Domestic Charger, 3 m charging cord
  • Key or Pedal Start: Pedal
  • Speed Controller: 235-amp AC Controller
  • Drive Train: Motor Shaft Direct Drive
  • Transaxle: Differential with helical gears
  • Gear Selection: Dash-mounted Forward-Neutral-Reverse
  • Rear Axle Ratio: 16.99:1 (Forward)
Performance
  • Seating Capacity: 4-Passenger
  • Weight w/o Batteries: 854 lb (387 kg) (without batteries)
  • Curb Weight: 900 lb (408 kg)
  • Vehicle Load Capacity: 800 lb (363 kg)
  • Outside Clearance Circle: 25.7 ft (7.83 m)
  • Speed: Up to 19.5 mph Commuter, up to 14.5 mph Links
Steering & Suspension
  • Steering: Self-compensating reduction rack and pinion
  • Suspension: Leaf springs with hydraulic shock absorbers
  • Service Brake: Dual rear wheel mechanical self-adjusting drum
  • Parking Brake: Self-compensating, single point engagement
  • Tires: Kruizer 185/60-14 (Commuter), Paramount M/T 23×10-14 (Explorer), Loadstar 205/65-10 (Links)
